High Lifter 6" Signature Series Lift Kit for Polaris Scrambler/Sportsman 850/1000- RED

Bigger. Badder. And now even more BOLDER. Take your ATV to the edge with High Lifter’s 6" Signature Series Lift Kit. Increase your ground clearance and make room for larger tires to dig deep and ride hard in most any terrain. Our engineers and staff have spent over 15 years perfecting the ultimate ATV lift kit. The product? The Signature Series Lift Kit is even easier to install with a bolt-on application that consistently measures truer over competitor products.

One of the first areas our team tackled was the steering. Large lifts are known for being difficult to steer. Our solution was superior engineering of steering components and hub location geometry that that provides excellent steering and maneuverability on the trails.

The kit provides a true 6"+ of lift with the front Max Clearance Control Arms featuring a 2" forward sweep for increased tire clearance and wheelbase. The rear Max Clearance Control Arms feature a 3" rearward rake for increased tire clearance and wheelbase. Depending on your shock preload adjustment, additional life can be gained.

Each lift kit comes with four Outlaw RCV Axles that are custom tuned for use with the 6” High Lifter Lift Kit. The max angles of 30 in the front and 34 in the rear are designed to promote a longer axle life compared to competitor big lifts that have high axle angles with more axle failure.

The Outlaw RCV axles are proudly built and assembled in the USA.  Assembled by High Lifter and Manufactured by RCV Performance, the makers of high performance drive line products.

•              The Outlaw RCV uses the RCV Performances patented cage
•              Sliding bars on both ends for increased angle capability
•              Bars, housings, cages, and races made of high strength alloy steel
•              Well established and proven design


The kit provides a true 6"+ of lift with the front Max Clearance Control Arms featuring a 2" forward sweep for increased tire clearance and wheelbase. The rear Max Clearance Control Arms feature a 3" rearward rake for increased tire clearance and wheelbase. The max axle angles are 30 degrees in the front and 34 degrees in the rear.

This 6" lift kit package includes the following components:

- Heavy duty laser cut front and rear upper lift/shock relocation brackets
- Eight custom heavy duty Max Clearance Control Arms crafted from 1 1/4"x.120 wall DOM tubing, heavy duty support gussets, and shock mounts
- Four Custom Outlaw RCV Axles
- Custom tie rods with heim-style rod ends
- Custom rear brake line kit
- All required hardware
- Detailed instructions with step-by-step photos



NOTE: All Outlaw RCV Axles MUST be registered with High Lifter within 30 days of purchase for warranty to be valid. Customer must register the Outlaw RCV Axles by sending the completed Axle Warranty Registration Card included in each axle box along with a copy of the original sales receipt to High Lifter.
